CodeMan®
Enterprise
- Welding
ASIS (Automated Self Issue Station)
[HOME] [NEWS]
|
|
ASIS Material Issue:
|
|
Electronically verifies
that the welder is qualified to perform welding using the specified WPS
and filler material.
|
|
The program evaluates the essential variables
of the WPS, evaluates the welder's current qualifications for the
particular WPS weld process and determines if the welder is qualified
to perform welds using the specified WPS and filler material.
|
|
|
|
Provides any welding
limitations that an approved welder may have for the specified WPS and
filler material.
|
|
The program determines any
weld code limitations that the welder may have for the particular
WPS/filler combination, such as limits for:
|
*
|
Material thickness;
|
|
*
|
Overlay thickness;
|
|
*
|
Weld deposit thickness;
|
|
*
|
Pipe/tube diameter;
|
|
*
|
Backing;
|
|
*
|
Filler;
|
|
*
|
Position;
|
|
*
|
Vertical progression;
|
|
*
|
Inert backing gas;
|
|
*
|
Visual or remote control;
|
|
*
|
Automatic joint tracking;
|
|
*
|
Etc.
|
|
|
|
|
Filler material is issued
to authorized welders and tied to the specified weld document and/or work
order.
|
|
Material issue record print outs contain issue
area information, date/time of issue, welder information (including
limitations), and issue material information.
|
|
|
|
Allows material issue records to be edited,
tracked, and printed.
|
|
|
Time stamps individual filler issue material for
exposure tracking.
|
|
|
|
ASIS Material Return:
|
|
Time stamps the filler material returned and
notifies user of exceeded filler material exposure limits.
|
|
|
If a return door has been established for the
filler material, the ASIS door is opened for the returned material.
|
|
|
If the administrative setting has been established
to update process use, the welder’s process use (continuity) is updated
when material is used.
|
|
|
The completed issue record is printed containing
applicable information about the issue.
|
|
|
|
ASIS Material Inventory Control:
|
|
Provides a means to add, edit, delete, and track
weld issue material.
|
*
|
Individual material stock numbers, as well as
lot and heat numbers, can be tied to the site and ASIS issue control
area.
|
|
*
|
Inventory amounts are decremented as material is
issued.
|
|
|
